Hello everyone 👋
My name is Vedant, and today’s article is about sharing textual content with other apps using the swift-android compiler. It will work for both Android & iOS mobile platforms. As you already know that sharing content with other apps is a widespread use case and we often want the app users to share some content with the other installed apps on the device. For example, you may want to share some textual content or a link with your friend or colleague on WhatsApp or Slack.
In this article (exclusively for the SCADE community), we will implement the textual content-sharing feature that works well for Android and iOS platforms.
So let’s start 😎.
If you haven’t installed the SCADE IDE, download the SCADE IDE and install it on your macOS system. The only prerequisite for SCADE is the Swift language (at least basics). Also, please ensure the Android emulator or physical device is running if you want to run SCADE apps on an Android device.
To keep it simple, let’s understand the concepts by creating a new SCADE project,
File -> New -> New Project. Then select the SCADE option, enter the project name, and click Create.
For the iOS implementation, we will use
UIActivityViewController class and will pass the text string which we want to share to other apps. So let’s create an instance of this class, and then pass rootView the SCADE application to the activity view controller instance.
// set up activity view controller #if os(iOS) let textToShare = [ text ] let activityViewController = UIActivityViewController(activityItems: textToShare, applicationActivities: nil) activityViewController.popoverPresentationController?.sourceView = self.rootView // present the view controller UIApplication.shared.delegate?.window??.rootViewController?.present(activityViewController, animated: true, completion: nil) #endif
popoverPresentationController parameter will attach the source view to the SCADE application’s
rootView. Finally, we will call the
present() method of the current rootViewController of the UIApplication global object. The parameter to be passed in the present() method is basically the instance of the
UIActivityViewController class that we have already created.
You can test the above code snippet. Yes, it works 😀! You can target a range of iOS devices and can easily share the textual content with other iOS apps.
Let’s implement it for Android
Before getting started with the implementation of the Sharing of the textual content constants for the Android platform, let us briefly discuss the swift-android compiler. SCADE developers have developed internally the swift compiler for the Android SDK (currently it is supporting API 24). The repository is now open source and anyone can use the existing Swift classes to develop various Android use cases.
We will use the
Intent(action: Intent.ACTION_SEND) the method with the action intent type of
ACTION_SEND parameter by creating an instance of the
/*Create an ACTION_SEND Intent*/ Intent intent = new Intent(android.content.Intent.ACTION_SEND); /*This will be the actual content you wish you share.*/ String shareBody = "Here is the share content body"; /*The type of the content is text, obviously.*/ intent.setType("text/plain"); /*Applying information Subject and Body.*/ intent.putExtra(android.content.Intent.EXTRA_SUBJECT, getString(R.string.share_subject)); intent.putExtra(android.content.Intent.EXTRA_TEXT, shareBody); startActivity(Intent.createChooser(intent, getString(R.string.share_using)));
As the next step of native Android implementation, we will set the intent data type to plain text and pass the content’s subject and description using the
putExtra() method. Finally, to display a list of apps to choose from, call the
startActivity() method and pass the Intent instance.
Swift compiler for Android code
The swift-android repository contains the swift classes which are generated from the Android SDK. We will inject the required classes into our SCADE app and achieve similar functionality accordingly. It uses SPM a lot to inject the necessary dependencies into the SCADE app.
For the Android code snippet above, we require the applicationContext and resources instance to call the necessary methods. We will add the below Android packages into
// swift-tools-version:5.3 import Foundation import PackageDescription let SCADE_SDK = ProcessInfo.processInfo.environment["SCADE_SDK"] ?? "" let package = Package( name: "ScadeDemoApp", platforms: [ .macOS(.v10_14) ], products: [ .library( name: "ScadeDemoApp", type: .static, targets: [ "ScadeDemoApp" ] ) ], dependencies: [ .package( name: "Android", url: "https://github.com/scade-platform/swift-android.git", .branch("android/24")) ], targets: [ .target( name: "ScadeDemoApp", dependencies: [ .product(name: "Android", package: "Android", condition: .when(platforms: [.android])), .product(name: "AndroidOS", package: "Android", condition: .when(platforms: [.android])), .product(name: "AndroidApp", package: "Android", condition: .when(platforms: [.android])), .product( name: "AndroidContent", package: "Android", condition: .when(platforms: [.android])), ], exclude: ["main.page"], swiftSettings: [ .unsafeFlags(["-F", SCADE_SDK], .when(platforms: [.macOS, .iOS])), .unsafeFlags(["-I", "\(SCADE_SDK)/include"], .when(platforms: [.android])), ] ) ] )
As the next step, we will now import these packages for Android in
import ScadeKit #if os(Android) import Android import AndroidApp import AndroidContent #endif
We are now ready to call the respective swift methods for the given above Java methods.
#if os(Android) let intent: Intent = Intent(action: Intent.ACTION_SEND) intent.setType(_type: "text/plain") intent.putExtra(name: Intent.EXTRA_SUBJECT, value: "The Subject of the Message") intent.putExtra(name: Intent.EXTRA_TEXT, value: text) Application.currentActivity?.startActivity(intent: intent) #endif
Let us understand the above code snippet and what it does basically. Firstly, we create an instance of
Intent the type of
ACTION_SEND. We set the content to be plain text.
In order to access the Application’s context, we use the
currentActivity instance which returns the context. Using this context, we call
startActivity the method to launch the implicit intent that we created in the first step.
Now we are good to test the code on Android devices. Set the target to any Android device you like and test if it is working as expected.
Voila🎊! We have successfully implemented the sharing of content with other apps using the swift-android compiler. This is one of the examples of coding cross-platform apps using the SCADE platform. Integrating any Android-specific feature is very easy into the SCADE app using the swift-android library. You should definitely try the swift-android to build some of the useful components to build cross-platform apps.
We will be releasing a series of articles related to the swift-android compiler. Thank you for reading and see you in the next article!
Happy Coding 😊
